Adam's high-performance Nimbus top loading precision balance features a large, chemical-resistant stainless steel top pan and 0.1g readability. Ideal for laboratory materials testing applications.

Nimbus balances feature a lightweight, compact construction which significantly reduces the footprint of the balance, making it easy to fit the balance on busy worktop areas or transport to new locations when necessary. The single-piece construction offers greater stability than standard balances for obtaining more accurate results whilst allowing chemicals and hazardous samples to be weighed with minimal risk of accidental spillage during handling.

The weighing sensor in the Nimbus is crafted from a single block, and contains fewer parts than a traditional force motor balance. This optimised internal mechanism is fabricated using hardened materials, helping the Nimbus tolerate rigorous laboratory use. Efficiency in the mechanics, plus improved processing power of the electronics, leads to excellent performance.

Key Specifications

Capacity
12000g to 22000g
Readability
0.1g
View all models

Features

  • Backlit displayBacklit display
  • Below balance weighingBelow balance weighing
  • DateDate
  • External calibrationExternal calibration
  • GLP/ISO Print ReportsGLP/ISO Print Reports
  • RS-232RS-232
  • Security lock downSecurity lock down
  • Tare FunctionTare Function
  • TimeTime
  • USBUSB

Applications

  • Density determinationDensity determination
  • Dynamic / animal weighingDynamic / animal weighing
  • Parts countingParts counting
  • Percentage weighingPercentage weighing
  • WeighingWeighing

Features and Benefits

Hardware

  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Robust metal housing protects internal components in harsh environments
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • Large, grade 304 stainless steel pan allows easy cleaning
  • Vivid, backlit LCD easily visible in any lighting conditions
  • Lockdown device to secure balance

Software

  • External calibration allows for verification and adjustment with weights
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Selectable digital filtering helps minimise effects of vibration and disturbances
  • Zero-tracking feature ensures display returns to zero reading
  • Multilingual display allows use in many different countries

Display

  • Vivid, backlit LCD easily visible in any lighting conditions

Power

  • AC adapter included

Models

Model Capacity Readability Pan Size Approvals Request a Quote
Picture of NBL 223eNBL 223e 220g 0.001g 120mm ø   Request a Quote
Picture of NBL 423eNBL 423e 420g 0.001g 120mm ø   Request a Quote
Picture of NBL 623eNBL 623e 620g 0.001g 160mm ø   Request a Quote
Picture of NBL 823eNBL 823e 820g 0.001g 160mm ø   Request a Quote
Picture of NBL 1602eNBL 1602e 1600g 0.01g 160mm ø   Request a Quote
Picture of NBL 12001eNBL 12001e 12000g 0.1g 400x300mm   Request a Quote
Picture of NBL 16001eNBL 16001e 16000g 0.1g 400x300mm   Request a Quote
Picture of NBL 22001eNBL 22001e 22000g 0.1g 400x300mm   Request a Quote
Picture of NBL 12001PNBL 12001P 12000g 0.1g 400x300mm   Request a Quote
Picture of NBL 16001PNBL 16001P 16000g 0.1g 400x300mm   Request a Quote
Picture of NBL 22001PNBL 22001P 22000g 0.1g 400x300mm   Request a Quote

Applications

Chemistry labs:

Nimbus top loading balances offer up to 0.1g resolutions for measuring small chemicals and samples. The stainless steel top pan is chemical-resistant and the balance comes with dynamic weighing features that can be used effectively when handling chemicals.

Materials testing:

The Nimbus top loading balance models include a larger weighing pan compared with standard Nimbus precision models. The balance can be fitted with a weigh below hook for carrying out density determination and gravity testing experiments on materials such as concrete.

Downloads

Manuals

Datasheets and Brochures

Accessories

Here is a list of our available related products and suitable accessories:

Product Image Product Name Item Number Link
Anti-vibration table Anti-vibration table 104008036 View
AdamDU Data Collection Program AdamDU Data Collection Program 600002028 View
AIP impact printer AIP impact printer 1120014641 View
ATP thermal printer ATP thermal printer 1120011156 View
Density kit for 0.001g Density kit for 0.001g 1060012714 View
In-use wet cover for 120mm ø and 160mm ø pan In-use wet cover for 120mm ø and 160mm ø pan 3012013010 View
RS-232 cable M-F RS-232 cable M-F 3014011014 View
In-use wet cover for 400x300mm pan In-use wet cover for 400x300mm pan 3012013012 View
Rechargeable Battery Pack Rechargeable Battery Pack 2010012712 View
USB cable USB cable 3074010267 View
Dust cover for 0.01g and 0.001g balances Dust cover for 0.01g and 0.001g balances 3012313008 View
Security cable Security cable 3014013041 View
Weigh-below hook Weigh-below hook 3021210953 View
Weigh-below hook for 400x300mm pan Weigh-below hook for 400x300mm pan 302126013 View
Calibration certificate Calibration certificate 700660290 View
