Highland® Portable Precision Balances: HCB 302

HCB 302
  • HCB 302 2
  • HCB 302 4
  • HCB 302 5
  • HCB 302 1
  • HCB 302 3
  • HCB 302 0

Key Specifications

Capacity
300g
Readability
0.01g
Repeatability
0.01g
Pan size
120mm ø

How to get your HCB 302

Contact us to receive a quote or to find your local dealer

Register your HCB 302

Click the link below for the warranty registration form.

The Highland® offers advanced features in a compact, durable balance that stacks for easy storage. Suitable for many tasks, Highland provides fast, accurate weighing in a number of different environments – from science research in the laboratory or field, to manufacturing operations.

Sturdy ABS construction allows the Highland to stand up to demanding lab use, while Highland's ShockProtect® offers advanced overload protection to keep the balance safe. HandiCal® facilitates internal calibration without the need for external weights.

HCB 302 Specifications

Capacity
300g
Readability
0.01g
Repeatability
0.01g
Weighing Units
g, lb, oz, N, GN, ct, dr, dwt, mm, ozt, T, tl.H, tl.S, tl.T
Calibration
External calibration / Internal manual calibration
00 Nav Number
700000063
Stabilisation Time
2.0
Pan Size
120mm ø
Linearity
0.02g
Power Supply
12VDC 50/60Hz 800mA adapter / Internal rechargeable battery
Construction
ABS plastic
Interface
RS-232, USB
Operating Temperature
0° to 40°C
Net Weight
2kg
Dimensions Overall
174x252x80mm (wxdxh)
Electrical Safety Mark
CE, cUL
Display Digit Height
18mm
Battery Life
24.0

View alternative models

Features and Benefits

Hardware

  • Balances stack efficiently and safely to save space (120mm pan size only)
  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • Dual tare keys facilitate operation with either the left or right handoperation
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Security slot for optional Kensington-type lock and cable to help prevent theft
  • Large, grade 304 stainless steel pan allows easy cleaning
  • Solid ABS housing is durable for industrial use
  • Three-point ShockProtect® feature helps prevent overload damage to internal components
  • Hook included for weighing below the balance
  • HandiCal® internal calibration eliminates need for external weight set
  • USB and RS-232 interfaces provide speedy communication with computers and printers

Software

  • Audible overload alarm warns when capacity is exceeded
  • External calibration allows for verification and adjustment with weights
  • Selectable digital filtering helps minimise effects of vibration and disturbances
  • Parts counting with preset sample sizes
  • Memory accumulation totals results
  • Zero-tracking feature ensures display returns to zero reading

Display

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Programmable backlight can be set to "always on," "always off" or "light only when weighing"
  • Capacity tracker built into display for easily monitoring possible overloads

Power

  • AC adapter included
  • Rechargeable battery included for operation almost anywhere
  • Programmable auto power-off to save energy

Downloads

Applications

  • AccumulationAccumulation
  • Parts countingParts counting
  • Percentage weighingPercentage weighing
  • WeighingWeighing

Technical Highlights

  • Backlit displayBacklit display
  • Internal rechargeable batteryInternal rechargeable battery
  • Below balance weighingBelow balance weighing
  • External calibrationExternal calibration
  • Internal calibrationInternal calibration
  • RS-232RS-232
  • Security lock downSecurity lock down
  • Tare FunctionTare Function
  • USBUSB
