Intuitive Operation, Dependability,
Performance and Value since 1972

Highland® Portable Precision Balances-HCB 2202

Availability: In stock
Capacity
2200g
Readability
0.01g
Pan Size
120mm ø
View alternative models
Highland® balances are well-suited for lab work, field use, and many industrial applications. The Highland features HandiCal® internal calibration with a built-in mass, and ShockProtect® as a safeguard against shock loading and accidental overload.
Warranty 3 yearsWarranty 3 years

Applications

WeighingWeighing
Parts countingParts counting
Percentage weighingPercentage weighing
AccumulationAccumulation

Features

Backlit DisplayBacklit Display
TareTare
Battery PowerBattery Power
RS-232RS-232
USBUSB
Weigh BelowWeigh Below
External CalibrationExternal Calibration
DateDate
TimeTime
GLPGLP
Internal CalibrationInternal Calibration
Security LockSecurity Lock
Multiple Weighing unitsMultiple Weighing units
Toggle icon descriptions
The Highland® offers advanced features in a compact, durable balance that stacks for easy storage. Suitable for many tasks, Highland provides fast, accurate weighing in a number of different environments – from science research in the laboratory or field, to manufacturing operations. Sturdy ABS construction allows the Highland to stand up to demanding lab use, while Highland’s ShockProtect® offers advanced overload protection to keep the balance safe. HandiCal® facilitates internal calibration without the need for external weights.

Features and Benefits

  • Vivid, backlit LCD easily visible in any lighting conditions
  • Programmable backlight can be set to "always on," "always off" or "light only when weighing"
  • Capacity tracker built into display for easily monitoring possible overloads
  • Balances stack efficiently and safely to save space (120mm pan size only)
  • Colour-coded keys facilitate quick recognition of the most frequently used buttons
  • Dual tare keys operate with either the left or right hand
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Large, grade 304 stainless steel pan allows easy cleaning
  • Solid ABS housing is durable for industrial use
  • Three-point ShockProtect® feature helps prevent overload damage to internal components
  • Hook included for weighing below the balance
  • HandiCal® internal calibration eliminates need for external weight set
  • USB and RS-232 interfaces provide speedy communication with computers and printers
  • AC adapter included
  • Rechargeable battery included for operation almost anywhere
  • Programmable auto power-off to save energy
  • Audible overload alarm warns when capacity is exceeded
  • External calibration allows for verification and adjustment with weights
  • Selectable digital filtering helps minimise effects of vibration and disturbances
  • Parts counting with preset sample sizes
  • Memory accumulation totals results
  • Zero-tracking feature ensures display returns to zero reading
  • Security slot for optional lock and cable to help prevent theft
  • A 3-year warranty means quality assured for years of use.

Technical specification

Model

HCB 2202

UPC: 840886101824

Metrology

  • Capacity
    • 2200g
  • Readability
    • 0.01g
  • Repeatability
    • 0.01g
  • Linearity
    • 0.03g
  • Min Weight USP
    • 0.5g

General Specifications

  • Pan size
    • 120mm ø
  • Weighing Units
    • ct, dr, dwt, g, GN, lb, mm, N, oz, ozt, T, tl.H, tl.S, tl.T
  • Stabilisation Time
    • 3
  • Interface
    • RS-232/USB
  • Calibration
    • External calibration/Internal manual calibration
  • Display
    • Backlit LCD with 18mm high digits

Power

  • Battery type
    • Lead Acid
  • Number of batteries
    • 1
  • Power Supply
    • 12VDC 800mA adapter / Internal rechargeable battery
  • Maximum Battery Life (in hours)
    • 24

Operating Conditions

  • Operating Temperature
    • 0° to 40°C / 32° to 104°F

Product Information

  • Construction
    • ABS plastic
  • Net Weight
    • 2kg

Dimensions

  • Draft Shield Type
    • Round
  • Overall dims
    • 174x252x80mm
