CBD Dual Bench Counting Scales

#1
The CBD dual bench counting scale delivers a flexible and robust solution for companies that perform both small and large counting tasks.
Achieve Increased counting capability by connecting the CBD to a remote platform. Productivity is optimised with the CBD, as only one person is needed to perform large tasks. The CBD can be found in factories, fulfilment centres, warehouses, and just about anywhere small parts are manufactured or packaged.
Checking individual pieces with the CBD is speedy, as the LCD displays total weight, unit weight and count. Tasks are streamlined, as the CBD's memory stores up to 100 PLUs, along with descriptions, unit weights and tare weights.
Features
Backlit display
Internal rechargeable battery
Date
External calibration
RS-232
Tare Function
Time
Applications
Accumulation
Check counting
Dual scale operation
Parts counting
Weighing
Features and Benefits
Hardware
- Colour-coded keys facilitate quick recognition of the most frequently used buttons
- Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
- Large, grade 304 stainless steel pan allows easy cleaning
- RS-232 interface is available to provide speedy connection to computers and printers
- Optional USB interface simplifies data communication
- Overload protection helps prevent damage to internal components
- Rugged construction stands up to industrial use
- Supports connection to platforms with up to four load cells
Software
- External calibration allows for verification and adjustment with weights
- Memory accumulation totals results
- Parts counting with freely selectable sample sizes
- Parts counting optimisation automatically refines piece weight as parts are added
- Preset tare function speeds the process of repetitive weighing
- Product look up (PLU) memory locations store a range of items for recall
- Programmable for counting to a preset number of parts
- Quick and easy configuration using the keypad
- Security password control prevents unauthorised access
- Zero-tracking feature ensures display returns to zero reading
- User can program alarm to sound when preset total is reached
Display
- Backlit LCD shows weight, unit weight and count in one convenient location
- Programmable backlight can be set to "always on," "always off" or "light only when weighing"
Power
- Rechargeable battery included for operation almost anywhere
- Programmable auto power-off to save energy
Models
Model | Capacity | Readability | Pan Size | Approvals | Request a Quote |
---|---|---|---|---|---|
![]() |
4kg | 0.1g | 225x275mm | Request a Quote | |
![]() |
8kg | 0.2g | 225x275mm | Request a Quote | |
![]() |
16kg | 0.5g | 225x275mm | Request a Quote | |
![]() |
32kg | 1g | 225x275mm | Request a Quote | |
![]() |
48kg | 2g | 225x275mm | Request a Quote |
Applications
Factories & warehouses:
Factories that require large amounts of stock to be weighed can utilise the CBD dual counting scale's ability to connect to a larger platform. Through this connection, larger weight capacities can be handled that allow multiple units of products to be weighed simultaneously.
Shipping & distribution centres:
The CBD can be connected to Adam's PT platform scale for increased weighing capacities and parts counting capabilities. With a larger platform area, multiple pallets, boxes and crates can be counted simultaneously, streamlining manual counting procedures.
Downloads
Manuals
- Manual (English): CBD Bench Counting Scales - CBD_UM_EN.pdf
- Manual (Français): CBD Bench Counting Scales - CBD_UM_FR.pdf
- Manual (Español): CBD Bench Counting Scales - CBD_UM_ES.pdf
Datasheets and Brochures
- Datasheet (English): CBD Bench Counting Scales - CBD-DS-A4-EN.pdf
- Datasheet (Deutsche): CBD Bench Counting Scales - CBD-DS-A4-DE.pdf
- Datasheet (Español): CBD Bench Counting Scales - CBD-DS-A4-SP.pdf
- Datasheet (Italiano): CBD Bench Counting Scales - CBD-DS-A4-IT.pdf
- Datasheet (Português): CBD Bench Counting Scales - CBD-DS-A4-PG.pdf
- Datasheet (Français): CBD Bench Counting Scales - CBD-DS-A4-FR.pdf
