AELP Pallet Weigh Beams

AELP pallet beams offers fast, precise mobile weighing, along with many other features suited for industrial environments.
Ideal for measuring oversized items, AELP pallet beams are outfitted with rugged built-in wheels and handles, making them easy to move. Enclosed channels with high-quality load cells provide accurate, repeatable measurements and are built to withstand the rigours of constant warehouse use.
Use the AELP with the GK or AE403 indicator for the desired range of features. AELP beams are equipped with approximately five meters of shielded cable.
Features and Benefits
Approval
- OIML-approved load cells
Hardware
- Low-profile beams allow easy pallet weighing using pallet trucks
- Approximately five-meter/15-foot shielded cable
- Heavy-duty rubber feet ensure stability of unit
- Integrated wheels permit easy movement
- Can be used with any Adam indicators
- Two beams per set
Models
Model | Capacity | Readability | Pan Size | Approvals | Request a Quote |
---|---|---|---|---|---|
![]() |
1000kg | 0.2kg | 120x1330mm | Request a Quote | |
![]() |
1000kg | 0.2kg | 120x1330mm | Request a Quote | |
![]() |
1000kg | 0.2kg | 120x1330mm | Request a Quote | |
![]() |
1000kg | 0.2kg | 120x1330mm | Request a Quote | |
![]() |
2000kg | 0.5kg | 120x1330mm | Request a Quote | |
![]() |
2000kg | 0.5kg | 120x1330mm | Request a Quote | |
![]() |
2000kg | 0.5kg | 120x1330mm | Request a Quote | |
![]() |
2000kg | 0.5kg | 120x1330mm | Request a Quote | |
![]() |
1000kg | 0.2kg | 120x1330mm | Request a Quote | |
![]() |
2000kg | 0.5kg | 120x1330mm | N/A | Request a Quote |
![]() |
3000kg | 1kg | 120x1330mm | Request a Quote |
Applications
Shipping & logistics:
The AELP pallet weigh beams are primarily designed to weigh heavy pallets of goods in warehouse environments. Whilst heavy, the beams can be placed together and safely stored after use.
Cattle weighing:
AELP pallet beams can be combined with cattle crushes, cages and platform in order to weigh cattle including cows, sheep and pigs. The AELP offers a particularly high weight capacity making them highly-effective cattle scales for use by farmers.
Zoos, vets & animal weighing:
Aside from weighing cattle, the AELP pallet beams can be used to weigh larger zoo animals including camels, kangaroos and lions. Vets may require larger weighing scales with higher capacities when dealing with larger animals in shelters; the AELP provides large weight capacities and the flexibility needed, allowing the user to connect the beams with a platform or cage.
Downloads
Manuals
- Manual (English): AELP Pallet Beams - GK_UM_EN.pdf
- Manual (English): AELP Pallet Beams - GC_UM_EN.pdf
- Manual (English): AELP Pallet Beams - AEP_UM_EN.pdf
- Manual (English): AELP Pallet Beams - AELP_UM_EN.pdf
- Manual (English): AELP Pallet Beams - AELP_setup_EN.pdf
- Manual (Français): AELP Pallet Beams - AELP_UM_FR.pdf
- Manual (Español): AELP Pallet Beams - AELP_UM_ES.pdf
- Manual (Multi_Language): AELP Pallet Beams - AELP_CM.pdf
Datasheets and Brochures
- Datasheet (English): AELP Pallet Beams - AELP-DS-A4-EN.pdf
- Datasheet (Français): AELP Pallet Beams - AELP-DS-A4-FR.pdf
- Datasheet (Italiano): AELP Pallet Beams - AELP-DS-A4-IT.pdf
- Datasheet (Português): AELP Pallet Beams - AELP-DS-A4-PG.pdf
- Datasheet (Deutsche): AELP Pallet Beams - AELP-DS-A4-DE.pdf
- Datasheet (Español): AELP Pallet Beams - AELP-DS-A4-SP.pdf
- Datasheet (中文): AELP Pallet Beams - AELP-DS-A4-CN.pdf
