The relay box is an add-on for the ABK, AFK, Warrior and the AE 402 Indicator. When installed, it allows the checkweighing limits to trigger a voltage relay. Once the trigger is set, the relay box will open or close a switch. This allows the scales to drive other items such as a motor for filling, or lights to signal the users. The relay box includes input for power to help drive the relays.

How to get your Relay box

Contact us to receive a quote or to find your local dealer

Features and Benefits

Features

  • 4 switches can be programed to operate with the checkweighing functions
  • Relays can be set up to drive 115/230VAC 1A or 24VDC 1A output
  • Input from user equipment can be accepted at 15-25VDC or 12-25VAC to power the relay circuit
  • Supplied with 12VDC 500mA adapter
  • Work with AE 402, Warrior, ABK and AFK models
